4782EL Series Short Backset Electric Mortice Locks

The 3782EL is a fully field configurable primary electric mortice lock providing significant benefit over previous models. The unique motor-driven operation, high-security monitoring capabilities and on-board door status LEDs provide a significant advancement in the specification, distribution, installation and servicing of electric mortice locks.

Model: 4782ELSS

Features

• Variable voltage from 9 28VDC
• Simple in-field selection of power to lock or power to open
• Full range of monitoring including Request to Exit (REX), Deadlatch, Door position, Key Override Monitoring (KOM) and locked status
• On-board door status LEDs improves installation and reliability
• Unique functions for the reader in / reader out applications which allow the external side to fail securely while the internal side fails safe allowing free egress
• Motor driven provides lower power usage in power to lock applications
• 3 wire control means the power can be supplied independently of the locking control signal making the lock less susceptible to issues associated with the voltage drop across long wiring runs
